55kW Cosmetic Wet Bead Mill 50L Ink Production Machine

Super Flow Wet Grinding 50L 100L Wet Bead Mill Used In Cosmetic Chocolate Water base

The main feactures of Wet Bead Mill Machine:

1. Main Materials : Silicon Carbide Ceramic inner chamber, dispersing disc: 316Stainless steel.

2. Low temperature: has lower temperature with Silicon Carbide Ceramic inner chamber.

3. Better fineness: Food or Cosmetic, totally meet the finally fineness, also with successful case in industry.

4. Enhanced efficiency: more 10-30% than traditional Bead mill.

Main Technical Parameter of 30L /50L /100L of Wet Bead Mill

The Configuration instructions information of Sand mill machines

1. Outer Chamber: 304 stainless steel

2. Inner Chamber: silicon carbide ceramics

3. Dispersing shaft: 40Cr with hard chromium plating

4. Dispersing disk: 316 stainless steel

5. Mechanical seal: Double Mechanical seal with Pressure of 0.45 Mpa,(patent technology)

6. Feeding and discharging end covers on the chamber: 304 stainless steel

7. Static discharge screen ring: 304 stainless steel screen ring with 304.Gaps: 0.5mm.

8. Feeding pump: diaphragm pump(G1 brand: Ingorsoll Rand)

9. Alarming system: applied for each machines or for your choice

10.Operating control: button type or PLC for your choice

The After Sales Service:

1. Video instructions for installation and commissioning, if need, we will arrange engineer to your factory.

2. 12-24H feedback any customers questions, firstly offer the video help you solving, if need, arrange maintenance engineer for you.

The package and shipping: Be covered with anti-abrasion film and then packed in wooden boxes, then sea shipping by FCL or LCL.

Also offered the related products: Dispersing machine & the Zirconical beads, This 2 products are much important for the Bead mills, this materials is pre-dispersing well, It's better for grinding with bead mill after pre-dispersing well. Also the zirconial beads (grinding beads with different size for meeting different finally fineness.

Note:
1.We will recommend the suitable bead mills according to your information and demand, such as industry, fineness, temperature, viscosity, production capacity etcs.
2. The Materials of inner chamber and Dispersing disks can be selected according to your different grinding materials and industries.
3. The control system will be matching of different demand, such as PLC or traditional Button type.

If need more detailed information and Price, please don't hesitate contact us, Also Warmly welcome to visit us.

Allwin Machine & Equipment Co., Ltd. is a Chinese national high-tech enterprise and specialized manufacturer of wet grinding, dispersing equipment, and production lines. Established in 1993 in Chongqing, China, we have been certified with ISO9001:2015.

With 30 years of industry experience, Allwin is committed to helping providing customers with full-process services from construction planning, product supply, to providing complete production lines, personnel training, and lifelong maintenance services.

Allwin specializes in the research and production of bead mills, mixers, dissolvers, customized production lines, tanks, and zirconia beads, with 30 years of industry experience and proficient in wet grinding core technology. We have sold more than 10,000 devices, serving 180 cities in China and exporting products to multiple countries.

Our customer base mainly covers Battery, Ceramics, Nanomaterials, Coatings, MLCC/LTCC, Pharmaceuticals, Food, Titanium dioxide, Personal Care, Papermaking, Inks, Pesticides, Graphene, Metallic and Non-metallic Minerals and more.

We have a professional R&D team, After-Sales Service team, Process Production department, run a Product Lifecycle Management (PLM) system. Our equipment is excellent, from materials to parts are all produced by CNC. The quality characteristics of our products are stable, reliable, interchangeable well, Precise, low noise, and long life. As a manufacturer, we comply with the ISO9001 standard strictly.

Allwin workshop:

Allwin Service:

1. Video instructions for installation and commissioning, if need, we will arrange engineer to your factory.

2. 12-24H feedback any customers questions, firstly offer the video help you solving, if need arrange maintenance engineer for you.

R & D Team：

1. Allwin has been authorized with more than 11 patents and established cooperation with universities. Allwin has more than 12 engineers for Design and optimizing.
2. Whole production solution: Allwin can offer the Whole production solution for you, from Dispersing to grinding, from accessories to grinding media.

Sales Team:

      Allwin have professional sales team for you, before order we will recommand the suitable mills for your according to your requiriments and materials characteristics.

Quality Team:

       Allwin have professional engineers and a strict QA& QC system, Our factory comply with the IS09001 standard strictly.

Production Team:

•      Advanced machining center and skilled operators.
