    Nano Materials Horizontal Sand Mill With PU / Ceramics Dispersing System

    Ask Lasest Price
    Brand Name : AllWin
    Model Number : HZPLUS250
    Certification : ISO9001
    Price : USD60000--USD200000/set
    Payment Terms : T/T, MoneyGram, Western Union
    Supply Ability : 30sets /month
    Delivery Time : 30-40 Working Days
    • Product Details
    • Company Profile

    Nano Materials Horizontal Sand Mill With PU / Ceramics Dispersing System

    HZPLUS 250 Horizontal Sand Mills For Nano Materials With PU/Ceramics Dispersing System


    Grinding LFP and and Aluminia ceramic powders or other namo materials needs many key and qualified machines to finish with iron separator, as its special requirement, the inner chamber and dispersing system need to match special requiement.For example , to grind lithium iron phosphate need to sheild any Fe, Cu, Zn elements, usually choosing the dispersing PU/ Zirconia ceramics as the dispersing system materials according to the water based or alcoholic based. Other fields like aluminia, ceramic powders, pesticides, namo inks , the slurry may contain solvents, therefore, it's very important to chose the proper dispersering system materials.

    According to our owned and counterparts' statics, our bead mills

    1.can help customer save more electricity fees,

    2.lower failure rate,as mechanical seals setting in lower pressure side can operate more steady

    3.can smoothly discharge with dynamic screen ring and discharge from central axis.


    The Configuration instructions

    NoMain partsHZPLUS 250Notes
    1Outter chamber304 stainless steel
    2Inner chamber

    Silicon Carbide Ceramics,
    stainless steel coated with PU

    3Dispersing shaft40Cr with hard chromium plating
    4Dispersing systemzirconia ceramics,stainless steel coated with PU
    5Feeding and discharging end covers on the cylinderstainless steel coated with PU/ Zirconia
    6Turbine centrifugal separatorzirconia ceramics,stainless steel coated with PU
    7Static discharge screen ringScreen ring with 304.Gaps: 0.3/0.5mm.calculate according to your viscosity or grinding medium
    8Mechanical seal

    Intelligent double mechanical

    seal with mandatory

    lubricating-cooling system

    9Feeding pump1"/1.5” ARO diaphragm pump;Ingersorand

    10

    Appliance configurationoperation column,electrical appliance boxes;electric contact pressure gauge, temperature,solenoid valves. Ex-proof/ non ex-proof is optional.
    11Maintainance rails

    1 set for free

    dispersing system with different materials

    The Advantages of HZPLUS Series:

    L 1. Great flow rate and super fine discharging

    2.High production capacity and high efficiency,

    3.Saving enegy 10-30%

    4.SIC silicon carbide ceramic inner chamber.

    5.Double mechanical sealing with research and development indepent technology


    The After sales service:

    1. Video instructions for installation and commissioning, if need, we will arrange engineer to your factory.

    2. 12-24H feedback any customers questions, firstly offer the video help you solving, if need, arrange maintenance engineer for you.


    The package and shipping: Be covered with anti-abrasion film and then packed in wooden boxes, then seashipping by FCLor LCL.

    other related products

    We can also offer other related products in production lines, like disperser, moving tank, zirconia bead, grinding medium charging&discharging machines, etc. there are some pictures for your referrence.


    We warmly welcome all potential customers to visit our factory, also welcome to send materials for testment.

    If need more detailed information and Price, please don't hesitate contact me,
