3. Each part of M Sigma Machine
1.3T Manual De-coiler
Diameter: 460-520mm expansion.
Capacity: 3 Tons
Max Coil Width: 500mm
2.Leveling device
Put the raw material(steel plate) through the beach to manufacture
and process
Diameter is Ø 76mm, chrome and HRC60 heat treatment to secure the
smooth surface.
7 rolls leveling, 3 rolls up and 4 rolls down,it can guarantee that the products are neat, parallel and
everything is uniformi
3. Punching and cutting device
It adopts the hydraulic drive and automatic location to decide the
dimension and cut the target products
hydraulic station pressure: 20 MPa
Hydraulic coil:46#
Components: It contains one set of blade, one hydraulic cylinder
and one cutter machine
cutting blade material:Cr12 Mov steel with high treatment
4.Control Box
(1) Power supplier: 380V, 50 Hz, 3Phase (adjusted with the
requestment)
(2). Control panel: Button-type switch and touch screen
(3) The language in the touch screen: English and Chinese
(4) Length & quantity measurement automatically.
(5) Length & quantity controlled by PLC.
(6) Length inaccuracy can be amended easily.
4.Application
This M shape sigma roll forming machine is the most popular machine
on the market.
All the sizes can be set on PLC control screen. and used widely in
steel construction area, the products are widely used as steel roof
and wall support frame of factory, warehouse, garage, gymnasium,
exhibition center, cinema, theatre, etc.
