4 Port Gigabit DIN PoE Switch
Model name: IM-FP244GE, it is fine to use your model name.
Rate: 100/1000Mbps
POE Standard: ieee802.3 af/at, 120W POE budget
Power Input: Redundant DC input, 48V
This 4 port din POE Ethernet switch unmanaged also features below
simple construction, plug-and-play
power range up to 100 meters
operating temperature -40℃ to + 75℃
meet IP40 protection degree
comply with FCC and CE standards
The reliable industrial-grade design could ensure continuous and
stable operation of the automation system
Key Features of Industrial PoE Switch
- Support power on POE IP cameras through the wireless access point
(AP) of 5 categories of Ethernet cable.
- IEEE 802.3af/at power on to 1 ~ 4 RJ45 ports
- 4x 10/100/1000Mbps Auto-sensing RJ45 ports
- 6KV Ethernet surge protection, adapt to a harsh outdoor environment
- Support Auto MDI/MDIX
IEEE 802.3 10Base-T and IEEE 802.3u 100Base-TX compliant
- Max power to 15.4W under af standard, 30W under at standard to each
PoE port
A store-and-forward switching mechanism
Flow control mode: full duplex with IEEE 802.3x standard,
half-duplex with Back pressure standard
Specification of PoE Fiber Switch
| Product Name | 10/100/1000Mbps Industrial POE Fiber Switch (2F+4TP) |
| Model No. | IM-FP244GE |
| Port | 2x 1000Mpbs SFP ports SM:1310nm/1550nm,20Km; 1490nm/1550nm,40~120Km MM:1310nm, 2Km; 850nm, 500-meter 4x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing) |
| Switching features | Transmission mode: storage and forward System bandwidth: 12Gbps (non-traffic jam) Packet Forwarding Rate: 8.928Mpps MAC: 4K Queue Buffer: 1.75M |
| Network media | 10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m) 100/1000BASE-TX: CAT5 or above shielded twisted pair(≤100m) SFP port,transmission distance: 20Km,40Km,60Km,80Km,100Km |
| LEDs | Power, network, fiber |
| Power supply | POE power supply input voltage: 48V (max 52V) Single PoE power supply output power: 30W (port 1~4)
Total budget: 120W PoE output voltage: 48V |
| Environment | Working temperature: -40～75°C Storage temperature: -40～85°C Working humidity: 10%～90%, non-condensing Storage humidity: 10%～95%, non-condensing |
| Industry Standards | EMI: FCC Part 15 Subpart B Class A, EN 55022 Class A EMS: EN 61000-4-2 (ESD) Level 3, EN 61000-4-3 (RS) Level 3, EN
61000-4-4 (EFT) Level 3, EN 61000-4-5 (Surge) Level 3, EN 61000-4-6
(CS) Level 3, EN 61000-4-8 Traffic Control: NEMA-TS2 Vibration: IEC 60068-2-6 Freefall: IEC 60068-2-32 Shock: IEC 60068-2-27 Rail Traffic: EN 50121-4 |
| Safety | CE Mark, commercial CE/LVD EN60950 |
| Mechanical information | Shell: Corrugated metal shell Safety class: IP40 Dimension: 158 x 115x 60mm Mounting method: Din-rail/Wall mounting |
| Warranty | Replacement within 1 year; 3 years repairing |
Packing List
The standard packing usually contains a 4 port POE switch, a
warranty card and a user manual.
Packing box dimension for 1pc: 25.3*20.8*8cm
Packing: 20pcs in a packing box of 67*33*47cm dimension.
Application of CCTV PoE Switch
FAQ
What is the PoE budget?
A: The standard PoE output is 30W per port.
Take IM-FP288GW for example, it has 8 PoE ports, so the budget is
30W/port*8 ports=240W.
We can also support 60W output if it is required, please confirm
with us.
How will you send my goods?
A: We will send the goods by DHL, UPS or FEDEX, please check the
delivery details by the tracking number.
Is it possible to print my logo?
A: Yes, it is usually on the top panel of the device.
Does the unit price include the fiber transceiver and power
adapter?
A: No, it is an industrial standard, but we have different options
for both.
What is the PoE output voltage?
A: Its DC48V for 802.3af/802.3at compliant powered devices such as
PoE cameras or PoE routers.
If the PD takes 24V power, then please use a PoE splitter to
connect our switch and powered device.
Do you accept sample order?
A: Yes. Sample order to check our services and quality.
