    Industrial Ethernet Media Converter Gigabit Unmanaged SC WDM Single Fiber Mini Size

    Ask Lasest Price
    Brand Name : OLYCOM
    Model Number : IM-MC110GE/SC
    Certification : CE, FCC, RoHS
    Price : Negotiable
    Payment Terms : T/T, Paypal
    Supply Ability : 3000 pieces per month
    Delivery Time : 3-5 working days
    • Product Details
    • Company Profile

    Industrial Ethernet Media Converter Gigabit Unmanaged SC WDM Single Fiber Mini Size

    Mini WDM Fiber Industrial Gigabit Optical Media Converter


    Key Features of Unmanaged Media Converter


    1. 1 x 10/100/1000Mbps Auto-sensing RJ45 ports
    2. 1 x 1000Mbps SC fiber ports
    3. 6 KV Ethernet surge protection, adapt to a harsh outdoor environment
    4. Support Auto MDI/MDIX
    5. Flow control mode: full duplex with IEEE 802.3x standard, half-duplex with Back pressure standard
    6. IEEE 802.3 10Base-T and IEEE 802.3u 1000Base-TX compliant
    7. A store-and-forward switching mechanism
    8. Operating environment temperature: -40°C～75°C

    Specification of Fiber Optic Converter


    Product NameMini Industrial Gigabit Media Converter
    Model No.IM-MC110GE
    Port

    1 x 1000Mpbs port
    SM: 1310nm/1550nm, 20Km1490nm/1550nm, 40~120Km
    MM:1310nm/850nm, 2Km/550m
    1x10/100/1000M UTP RJ45(Support MDI/MDIX auto-sensing)

    Switching features

    Transmission mode: storage and forward
    System bandwidth: 4Gbps (non-traffic jam)

    MAC: 4K

    Packet buffer size: 1.75Mb

    Network media

    10BASE-T: CAT3, CAT4, CAT5 un-shielded twisted pair(≤100m)
    100BASE-TX: CAT5 or above shielded twisted pair(≤100m)
    SC port transmission distance: 20Km,40Km,60Km,80Km,100Km

    LEDsPower, network, fiber
    Power supply

    Input voltage: DC 12-52V
    No-load power: 5W
    Reverse connection: support

    Environment

    Working temperature:-40°～ 75°C
    Storage temperature:-40°～ 85°C
    Working humidity:10%～90%,non-condensing
    Storage humidity:10%～95%,non-condensing

    Industry Standards

    ESD: IEC61000-4-2, ±15KV air, ±6KV contact

    EFT: IEC61000-4-4, General ±6KV

    Surge: IEC61000-4-5, Differential ±2KV, Common±6KV

    Safety

    CE-EMC: EN 55032:2015+AC: 2016+A1:2020+A11: 2020
    EN 55035:2017+A11: 2020/EN IEC 61000-3-2:2019/A1: 2021
    EN 61000-3-3: 2013/A2: 2021/AC:2022
    CE-LVD: EN IEC 62368-1: 2020+A11:2020
    FCC: 47 CFR FCC Part 15 Subpart B(Class B) ANSI C63.4: 2014

    Mechanical information

    Shell: Corrugated metal shell, IP40 grade level

    Dimension: 114*93*35mm

    Mounting method: Din-rail/Wall mounting

    Weight: 0.35Kg/0.45Kg(Net/Gross)

    Warranty3 years


    Application



    Quality Assurance


    1. We absolutely never use old and refurbished materials.
    2. Always a pre-production sample before mass production.
    3. Have professional engineers check the quality.
    4. All products have passed CE, FCC, ROHS, and other certifications.
    5. Always final Inspection before shipment.
