40Khz 800w Ultrasonic Replacement Dukane Converter with Red Valve
Body
Description:
This 41C28 Ultrasonic Dukane converter is identical to the
41C29-129 with different mount BNC 40khz machine-mountable probe.
Ultrasonic Converters and Ultrasonic Transducers are one in the
same. There is one Ultrasonic OEM, Dukane Corporation, that uses
the term Transducer. All of the other ultrasonic OEM manufactures
such as Branson, Sonics and Materials, Rinco, Telesonics and
Herrmann refer to these as Converters or Konverters.
Specifications:
| Model | QR-D41C28 |
| Frequency | 40 khz |
| Output power | 800 watt |
| Joint bolt | M8*1.25 |
| Ceramic disc Diameter | 35mm |
| Qty of ceramic discs | 2pcs |
| Capacitance | 3-8nf |
| Amplitude | 4 um |
| Application | Plastic welding machine |
Ultrasonic transducer process differentiation can be divided into
the following points:
1. It can be identified from the manufacturing process and
appearance of the ultrasonic transducer. The transducer indirectly
shows that the company pays attention to the quality of the
product, and the quality of the process and appearance is naturally
better. Moreover, the design process indirectly affects the quality
of production.
2. It can be identified according to the process design and
application data of the ultrasonic transducer, but this requirement
is very understandable and experienced for the transducer data.
Whether the design can be reasonably determined should be based on
the selection of materials. The quality of the data indirectly
affects the quality of the product. The same specifications of the
origin of the data is not the same, the quality will vary greatly.
3. Parameter detection, whether the parameters of the ultrasonic
transducer can be matched with the parameters of the electric box,
can it reach the ideal effect.
