NL6448BC26-27C NLT AUO LCD Panel 8.4 Inch LCM 640×480 RGB Vertical Stripe Pixel Format

    Buy cheap NL6448BC26-27C NLT AUO LCD Panel 8.4 Inch LCM  640×480 RGB Vertical Stripe Pixel Format from wholesalers

    Buy cheap NL6448BC26-27C NLT AUO LCD Panel 8.4 Inch LCM  640×480 RGB Vertical Stripe Pixel Format from wholesalers
    • Buy cheap NL6448BC26-27C NLT AUO LCD Panel 8.4 Inch LCM  640×480 RGB Vertical Stripe Pixel Format from wholesalers

    NL6448BC26-27C NLT AUO LCD Panel 8.4 Inch LCM 640×480 RGB Vertical Stripe Pixel Format

    Ask Lasest Price
    Brand Name : AUO
    Model Number : NL6448BC26-27C
    Certification : ISO9001
    Payment Terms : T/T, Paypal, Western Union, MoneyGram
    Supply Ability : 500PCS/DAY
    Delivery Time : 2-3 working days after payment confirmation
    • Product Details
    • Company Profile

    NL6448BC26-27C NLT AUO LCD Panel 8.4 Inch LCM 640×480 RGB Vertical Stripe Pixel Format

    NL6448BC26-27C NLT 8.4 inch LCM 640×480 Brightness 900 for Indsutrial Application

    NL6448BC26-27C Information

    Panel ModelNL6448BC26-27C
    Panel BrandNEC
    Descritiona-Si TFT-LCD ,8.4 inch, 640×480
    Panel Typea-Si TFT-LCD
    Display ModeTN, Normally White, Transmissive
    Active Area170.88×128.16 mm
    Outline200×152 mm
    SurfaceClear, Hard coating (2H), Antireflection
    Contrast Ratio1000:1 (Typ.)
    Display Colors262K/16.7M (6-bit / 6-bit + Hi-FRC) , CIE1931 40%
    Response Time3/15 (Typ.)(Tr/Td)
    Viewing Angle80/80/80/80 (Typ.)(CR≥10) (L/R/U/D)
    Frequency60Hz
    Lamp Type4 strings WLED Without Driver
    Signal InterfaceLVDS (1 ch, 6/8-bit) , 20 pins
    Input Voltage3.3V (Typ.)

    NL6448BC26-27C Basic Information

    Panel ModelNL6448BC26-27C
    Panel BrandNEC
    Descritiona-Si TFT-LCD ,8.4 inch, 640×480
    Panel Typea-Si TFT-LCD
    Operating Temperature-30 ~ 80 °C
    Storage Temperature-30 ~ 80 °C
    Vibration Resistance2.0G (19.6 m/s²)
    RemarksST-NLT, ColorXcell

    NL6448BC26-27C Mechanical Features

    Dot Resolution640(RGB)×480 (VGA)
    Pixel ConfigurationRGB Vertical Stripe
    Pixel Density95 PPI
    Aspect Ratio4:3 (H:V)
    Form FactorFlat Rectangle Display
    Dot Pitch0.089×0.267 mm (H×V)
    Pixel Pitch0.267×0.267 mm (H×V)
    Weight260/280g (Typ./Max.)
    SurfaceClear, Hard coating (2H), Antireflection
    Active Area170.88×128.16 mm (H×V)
    Bezel Area174.0×131.4 mm (H×V)
    Outline Dimension200×152 mm (H×V)
    Outline Depth8.2±0.5 mm
    Holes & BracketsFace mounting holes (4-Φ2.8)

    NL6448BC26-27C Electronics Feature

    Vertical Frequency60Hz
    Reverse ScanYes (180°)
    Total Power Consumption5.0W (Typ.)


    Packaging & Delivery
    Packaging: Safety Package For all of our LCD Screen Panel Replacements.
    Details: 1. Antistatic bag
    2. Layers of cartons
    3. Foam Box
    4. Carton Box.
