Soft Silicone Thermally Conductive Gel 6.0W/MK China Manufacturer
For LED Lighting
Company Profile
Dongguan Ziitek Electronic Material Technology Co., Ltd. was
established in 2006. Is a high-tech enterprise specializing in the
research, development, production and sales of thermal interface
materials. We mainly produce: heat-conducting joint filler, low
melting point thermal interface materials, heat-conducting
insulator, heat-conducting adhesive tape, heat-conducting interface
pad and heat-conducting grease, heat-conducting plastic, silicone
rubber, silicone rubber foam, etc. We adhere to the business
philosophy of "survival by quality, development by quality", and
continue to provide the most efficient and best service for new and
old customers with excellent quality in the spirit of rigor,
pragmatism and innovation.
Products description
TIF®060-16 is a soft silicone gel-based gap filler pad, formulated with
a special blend of fillers to provide both excellent thermal
conductivity and superior softness. Compared to conventional
thermal greases, TIF®060-16 has a higher viscosity, which effectively prevents filler
separation from the silicone matrix and reduces filler migration,
helping maintain consistent thermal performance. It is applied in a
similar manner to thermal grease and is suitable for commercial
dispensing or automated equipment. Typical applications include
flip-chip microprocessors, PPGAs, micro BGA packages, BGA packages,
DSP chips, circular silicon chips, LED lighting, and other
high-power electronic components.
Feature
> Thermal conductivity: 6.0 W/mK
> Soft, very low compression
> Low thermal impedance
> Operate automatically
> Proven long-term reliability
Application
> Heat-sink & frame
> LED backlight module, LED lighting
> High speed hardware driver
> Micro heat pipe
> Vihicel enginee controller
> Telecom industry
> Semiconductor automatic laboratory equipment
| TIF®060-16 Typical Properties |
| Property | Value | Test method |
| Color | Purple | Visual |
| Construction & Composition | Ceramic filled silicon material | - |
| Flow Rate(g/min) | 36 | Ziitek Test Method (30 cc syringe/ 2.5 mm orifice/ 90 psi) |
|
| Density(g/cc) | 3.40g/c | ASTM D297 |
| Thermal conductivity | 6.0W/mK | ASTM D5470 |
| Thermal Impedance @10psi (℃.in²w) | 0.071 | ASTM D5470 |
| Thermal Impedance @50psi (℃.in²w) | 0.055 | ASTM D5470 |
| Recommended Operating Temp | -45 ~200°C | Ziitek Test Method |
| Dielectric Strength(V/mm) | ≥4000 | ASTM D149 |
| Bond Line Thickness(mm) | 0.2 | Ziitek Test Mothod |
| Flame Rating | V-0 | UL 94 |
| Shelf Life | 12 months | - |
Product Specification:
30 cc/pcs, 98 pcs/box; 300 cc/pcs, 6 pcs/box.
Custom packaging available for automation use. Please contact us
for confirming.
If you want to know our thermal products, please visit our website.
Certifications:
ISO9001:2015
ISO14001: 2004 IATF16949:2016
IECQ QC 080000:2017
