Horizontal Fire Resistant Low Smoke Cables , 4 Pair Category 6 Ethernet Cable

Name: Horizontal Fire Resistant Low Smoke Cables 4 Pair Category 6 Ethernet Cable
Brand: Shenzhen Chengtiantai
Price: 1 USD

Ask Lasest Price
Brand Name :	Shenzhen Chengtiantai
Model Number :	UTP Category 6 LSZH Cable
Certification :	CE,UL& ROHS
Price :	on request
Payment Terms :	L/C, T/T
Supply Ability :	50,000 m/day
Delivery Time :	7 / 15 working days

Add to Cart

Product Details
Company Profile

Horizontal Fire Resistant Low Smoke Cables , 4 Pair Category 6 Ethernet Cable

Low Smoke Zero Halogen Horizontal Copper Cable,category 6,4 pair,UTP,LSZH,23 AWG,305 m,blue

LSZH Cable Category 6, 4 Pair, UTP solid copper

We supply a comprehensive range of Low Smoke Zero Halogen (LSZH) cables for use in applications where smoke emission and toxic fumes could pose a risk to human health and essential equipment in the event of a fire.

They are therefore often specified indoors, especially in public areas, and in other hazardous environments and poorly ventilated areas.

Unlike PVC cables and those made of other compounds which produce vast amounts of dense black smoke, toxic fumes and acid gas when exposed to fire, LSZH cables produce very low levels of smoke and toxic fume and no acid gases.

STANDARDS / REFERENCES:

International:

– ANSI/TIA 568-C.2

– UL 1666

– RoHS Compliant Directive 2011/65/EU

– UL 444

– ISO/IEC 11801 Ed. 2.0 (Class D)

National:

– YD/T1019-2001

Color Code:

Pair 1: Blue-White/Blue

Pair 2: Orange-White/Orange

Pair 3: Green-White/Green

Pair 4: Brown-White/Brown

Construction

Inner conductor Ø:

Conductor material:

Core insulation:

Separator:

Outer sheath material:

Sheath thickness:

Outer diameter:

23 AWG(0.56 mm)

Solid bare annealed copper

PE | Polyolefin

cross filler

LSZH

0.55 mm

6.2 mm

Dimensions

Length:

Cable weight:

Wire size:

Overall diameter of insulation:

Overall outside diameter:

305 m /1000 ft

12.6 kg

23 AWG (Ø 0.56 mm)

1.02 mm

6.2 mm

Electrical characteristics

ANSI/TIA Category

Characteristic Impedance (Frequency: 1-200 MHz)

DC Resistance Unbalance, maximum

DC Resistance , maximum at 20˚C

Delay Skew

Mutual Capacitance

Nominal Velocity of Propagation (NVP)

Coupling attenuation at 30˚C

Operating Frequency, maximum

Safety Voltage Rating

Dielectric Strength, minimum

100 ± 15 ohms

5 %

9.38 ohms/100 m

≤45 ns

5.6 nF/100 m @ 1 kHz

69%

45MHz(dB)

150 MHz

80 V

1500 Vac | 2500 Vdc

Mechanical Properties

Maximum operating temperature:

Operating Temperature Range:

Installation temperature:

Minimum bending radius:

Maximum pulling force

70˚C

-20˚C to 60˚C

0˚C to 60˚C

4 x cable diameter

100 N

Nominal Transmission characteristics(at 20℃)

requency	Attenuation (Max)	PS NEXT (Min)	NEXT (Min)	PS ELFEXT (Min)	ELFEXT (Min)	TCL (Min)	EL TCL (Min)	RL (Min)
MHz	dB	dB	dB	dB/100m	dB/100m	dB	dB	dB
4	3.8	63.3	66.3	53	56	44	23	23
8	5.3	58.8	61.8	46.9	49.9	41	16.9	24.5
10	6	57.3	60.3	45	48	40	15	25
16	7.6	54.2	57.2	40.9	43.9	38	10.9	25
20	8.5	52.8	55.8	39	42	37	9	25
25	9.5	51.3	54.3	37	40	36	7	24.3
31.25	10.7	49.9	52.9	35.1	38.1	35.1	/	23.6
62.5	15.4	45.4	48.4	29.1	32.1	32	/	21.5
100	19.8	42.3	45.3	25	28	30	/	20.1
200	29	37.8	40.8	19	22	27	/	18
250	32.8	36.3	39.3	17	20	26	/	17.3

MANUFACTURING PROCESS OF LAN CABLE

Mannufacturing plant

R&D Building

Bird's eye view of the plant

1st. Copper rod

2nd. Wire drawing&Annealing
3rd. Core insulation
4th. Wire twisting
5th. Wire backing twisting
6th. Cabling
7th. Jacking

8th. Testing
9th. Packing

CUSTOMER SERVICES:

We manufactures a comprehensive array of wires and cables to meet diverse market needs.

we supply a wide range of category 5e, category 6, category 6 A cable. If this all seems a litle too technical for you, then why not get in touch with us.

We look forward to assisting you in identifying the best products for your specific application and to answer any questions you might have.

Tel:+86 755 6114 5028

Fax:+86 755 61137976

E-mail : cttcable@hotmail.com

Shenzhen chengtiantai cable operates certified management systems compliant with: ISO 9001:2008 / ISO 14001:2004 / OHSAS 18001:2007

● Cable production started 1983
● 35 years of cable manufacturing experience

● Sales in 2016 about 500 million USD

● 100,000 m² Production area
● 350 Will-trained employees

● 8 workshop
● 1 R&D Center

Head office: chengtiantai Industrial Park, Lisonglang community, Gongming office, Guangming district, Shenzhen P.R. China 518106

* We do not advise the use of CCA (copper coated aluminum) cables to anyone who values their networks performance
