black 18 um very low profile electrodeposited copper foil for CCL
Products Detail.
Back and red color.
Thickness: 1/2 OZ,Width: 5-1380 mm.
Cu Content: 99.8%.
Product Characteristic.
- Excellent etching performance.
- Very Low profile enables to make fine circuit pattern.
- High elongation.
VLP ED copper foils use:
- Super fine pattern PWB.
- Chip on flex (COF) for LED.
Difference between rolled copper foil and electrolytic copper foil.
- Process is difference: rolled copper foil (Rolling process),ED copper foil
(Electrodeposition process).
- Performance is different ,Strength toughness: rolled copper foil is a flaky crystalline structure, so the
strength and toughness is better than electrolytic copper foil, so
most of the rolling copper foil used in flexible printed circuit
boards.
RFQ:
Q1: What's your delivery time ?
A: The common delivery time is 5-35 working days. The specific
delivery time depends on the items and the quantity of your order.
Q2: Can you supply the sample?
We can supply samples to check the quality before bulk order. But
the price will be sample price not wholesale price.
Q3. what is your standard width?
A: 1295mm,we accept customization for the width. we can cut it into
any size that you demand after pass discussing.
Typical properties of VLP ED copper foil(for FPC or inner layer of HDI)
Classification
| Unit | Requirement | Test Method |
| Foil Designation | / | | 1 | H | M | 1 | IPC-4562A |
| Nominal thickness | / | 10um | 12um | 1/2 OZ (18um) | 3/4 OZ(25um) | 1 OZ(35um) | IPC-4562A |
| Area Weight | g/㎡ | 98±4 | 107±4 | 153±5 | 228±8 | 285±10 | IPC-TM-650 2.2.12.2 |
| Purity | ％ | ≥99.8 | IPC-TM-650 2.3.15 |
| Foil Profile | Shiny side(Ra) | սm | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 | IPC-TM-650 2.3.17 |
| Matte side(Rz) | um | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 | ≤2.5 |
| Tensile Strength | R.T.(23℃) | Mpa | ≥300 | ≥300 | ≥300 | ≥300 | ≥300 | IPC-TM-650 2.3.18 |
| H.T.(180℃) | Mpa | ≥200 | ≥200 | ≥200 | ≥200 | ≥200 |
| Elongation | R.T.(23℃) | ％ | ≥4 | ≥5 | ≥6 | ≥8 | ≥10 | IPC-TM-650 2.3.18 |
| H.T.(180℃) | ％ | ≥5 | ≥6 | ≥7 | ≥8 | ≥8 |
| Peel Strength(FR-4) | N/mm | ≥0.8 | IPC-TM-650 2.4.8 |
| Ibs/in | ≥4.6 |
| Pinholes&porosity | Number | No | IPC-TM-650 2.1.2 |
| Anti-oxidization | R.T.(23℃) | 180days | / |
| H.T.(200℃) | 60 Minutes | / |
Standard Width 1295mm,max width 1380(±1)mm,May according to the
customer request tailor.We test the peel strength with PI ,please
reconfirm with your pp.
