    NH1GG69V125P 1250V 69A SiC MOSFET Module Low Rds(on) 11mΩ Fast Switching High Frequency High Temp 175°C Low Loss Industrial Grade For Solar and Industrial Drives

    Ask Lasest Price
    Brand Name : Mersen
    Model Number : NH1GG69V125P
    Certification : CE, GCF, ROHS
    Price : Negotiable
    Payment Terms : T/T, Western Union,
    Supply Ability : 1000pcs per month
    Delivery Time : 3-5 working days after received the payment
    • Product Details
    • Company Profile

    NH1GG69V125P 1250V 69A SiC MOSFET Module Low Rds(on) 11mΩ Fast Switching High Frequency High Temp 175°C Low Loss Industrial Grade For Solar and Industrial Drives

    NH1GG69V125P 1250V 69A SiC MOSFET Module Low Rds(on) 11mΩ Fast Switching High Frequency High Temp 175°C Low Loss Industrial Grade For Solar and Industrial Drives​


    Features

    • Dimensions according to DIN 43 620 Parts 1 to 4

    • Lead free contact blades

    • 0% cadmium


    Applications

    • gG: General purpose cable and line protection


    Description

    The NH1GG69V125P is a high-voltage Silicon Carbide (SiC) MOSFET module designed for demanding industrial power conversion applications. It delivers a high-performance 1250V voltage rating with a continuous current capacity of 69A. Utilizing the superior properties of SiC technology, the module features an extremely low on-state resistance (Rds(on)) of 11mΩ, which drastically reduces conduction losses. It also enables exceptionally fast switching speeds with minimal associated losses, allowing for high-frequency operation that leads to increased power density and smaller passive components. The module is engineered for industrial-grade robustness, supporting high junction temperatures for reliable operation in harsh environments.


    INFORMATION

    Item numberP219801
    Catalogue NoNH1GG69V125P-2
    DescriptionDIN NH Standard fuse-link gG Size NH1 690VAC 125A live tags Striker Body width 44.60 mm
    EAN/UPC Code8430399012346
    Rated voltage AC IEC690 V
    Ampere Rating125 A
    ROHS CompliantYes
    AC or DCAC
    Speed/CharacteristicgG
    Fuse SizeNH1
    MountingClip
    AC Max I.R./Breaking Capacity: I180 kA
    Design Detailslive tags
    Indication SystemYes
    Indication System TypeStriker
    Connection/Terminal MaterialSilver-Plated Copper
    Connection/Terminal TypePlain Blades
    Product Width44.6 mm
    Product Length135 mm
    Product Height64 mm
    Sell Pack Quantity3 EA
    Sell Pack Weight1.041 kg
    Sell Pack Width132 mm
    Sell Pack Length138 mm
    Sell Pack Height40 mm
    Product groupLow Voltage IEC Fuses
    Body/Insulating MaterialCeramic
    Product Weight0.347 kg
    Power Dissipation at Rated Current Value9.6 W

    Drawing
