MPO-8FC OM3 Fiber Optic Fanout Patch Cable – 8-Core MPO to FC
Breakout
Product Overview
Ruiara’s OM4 MPO-12FC breakout assembly offers a premium solution
for 12-core multimode distribution. With precise MPO alignment and
high-stability FC connectors, it supports efficient routing in
high-density cabinets, optical test systems, and data center
infrastructures.
Features
Ø Lower Insertion Loss & Higher Performance
Ø Low IL and stable signal transmission ensuring your network safety
Ø High-quality MTP connectors and guaranteed by 3D interferometer
Ø 100% factory tested
Specifications
Connector A | MPO (Female) | Connector B | FC UPC (12) |
Fiber Mode | 50/125μm OM4 | Cable Diameter | 3.0mm |
Fiber Count | 12 | Wavelength | 850nm /1300nm |
Breakout Length | 0.5m | Cable Diameter | 3 mm round trunk, 2.0 mm tails |
Cable Jacket | LSZH | Insertion Loss | MPO≤0.35dB ; FC≤0.3dB |
Jacket Color | Magenta | Return Loss | MPO≥60 dB, FC≥50dB |
Operate Temperature | -40~75°C | Durability | ≥500 times |
Applications
Ø QSFP to SFP+ Connection
Ø QSFP+ to SFP+ Connection
Ø PSM4 to SFP+ Connection
Ø 40GE to 10GE Interconnection
Ø 400G to 100G Interconnection
How to choose correctly the cable jacket: PVC, LSZH or OFNP?
Fiber patch cables are now widely used for indoor applications like
buildings, factories, office parks, campuses and so on. Whether you
choose PVC, LSZH or OFNP jacket depends on where you're going to
run the cable.
The features of PVC, LSZH and OFNP Jacket are as follows:
Ø PVC cable resistant to oxidation and degradation, it is commonly
used for horizontal runs from the wiring center.
Ø LSZH cable has a special flam-retardant coating, it is between
floors in a building.
Ø OFNP cable is space within the building created by building
components, design for the movement of air. It is usually work for
vertical runs beween floors.
