Description:
CG150, electric kick start engine, 12V8 full-wave AC, manual
clutch; dedicated headlights, taillights, turn signals;
chrome-plated steel spoke wheels; front tire 2.75-18, rear tire
3.00-18; chain drive; ordinary left and right handrails; ordinary
rearview mirror. Can be adapted to MP3, anti-theft device, USB
charger, mobile phone holder, rear shelf, bumper.
Specifications:
| Item | Parameter |
| Dimensions (Length x Width x Height) | 20300×7500×1310mm |
| Seat Height | 840mm |
| Wheelbase | 1310mm |
| Minimum Ground Clearance | 175mm |
| Maximum Load | 150kg |
| Steering Angle | 35 |
| Side Stand Tilt Angle | 14 |
| Ride Capacity | 2 Person |
| Dry Weight | 118kg |
| Fuel Tank Capacity | 15L |
| Front Braking System | Disc brakes |
| Rear Braking System | Drum brakes |
| Front Tire Size | 2.75-18 |
| Rear Tire Size | 3.00-18 |
| Battery Size | 12V/6.5Ah |
| Engine Type | Single cylinder, air-cooled, four-stroke |
| Engine displacement | 149 |
| Bore x stroke | 62×49.5 |
| Compression ratio | 9.0:1 |
| Maximum power | 8.5/8500(kW/r/min) |
| Maximum torque | 10/6500-7500(N·m/r/min) |
| Maximum speed | 90km/h |
| Start-up acceleration | 14S |
| Overtaking acceleration | 13S |
| Lubrication method | Pressure, Splash |
| Oil volume | 1.1L |
| Clutch type | Multi-plate wet clutch, manual |
| Ignition method | CDI |
| Spark plug | A8RTC |
| Starting method | Electric kick starter |
| Transmission method | Chain drive |
| Final gear ratio | 15:43 |
Frequently Asked Questions:
Q1. About us:
A: Jiangmen Songfeng Import and Export Co., Ltd. is the export arm
of our manufacturing facility, Yuanhua Technology Co., Ltd. We provide factory-direct pricing and strict quality control,
ensuring you receive competitive products straight from the source.
Q2. Payment Terms:
A: We require 30% deposit to begin production preparation, with the
remaining 70% due upon completion before loading.
Q3. Delivery Timeline:
A: Depending on the order quantity, usually around 45 working days
Q4. Customization:
A: We can meet OEM requirements and, with the customer's
authorization, use the customer's brand. Displacement and other
configurations can be modified upon request.
Q5. Packaging Parameters:
A: The size of SKD is 1760×460×840mm, and a 40HQ container can hold
96 units.
The size of CKD is 1160×880×380mm, and a 40HQ container can hold
154 units.
Q6. Minimum Order Quantity:
A: We usually recommend MOQ a 40HQ, which can be mixed with
different complete motorcycles and spare parts. Appreciate your
understanding that we do not handle retail exports.
Q7. After-sales Service:
We provide 24-hour online support to resolve quality issues at any
time and guarantee the supply of all original spare parts to ensure
your worry-free after-sales experience.
