    Used FINE LINE 1400ZL PERF Protection level IP 20

    Ask Lasest Price
    Brand Name : FINE
    Model Number : 1400ZL
    Payment Terms : L/C,D/A,T/T,Western Union
    Supply Ability : 120
    Delivery Time : 5
    • Product Details
    • Company Profile

    Used FINE LINE 1400ZL PERF Protection level IP 20

    FINE LINE 1400ZL PERF

    Product Overview

    The FINE LINE 1400ZL PERF is a 1400W pattern-imaging and cutting computer light. Integrating cutting-edge computer lighting technologies such as intelligent fan control, encoder positioning, and primary and secondary reflector designs, it is a cost-effective product specifically designed by Caiyi Lighting for the rental market. Its unique optical design not only delivers a uniform light spot and surpasses the lighting efficiency of 1500W computer lights on the market, but also allows for atomization through focus adjustment without changing the spot size or luminous flux output. The 140mm diameter lens delivers a total luminous flux of over 35,000 lumens. The XY axes utilize a contactless magnetic rotary encoder for positioning, improving positioning accuracy by over five times compared to optocoupler positioning. Its modular design and software compatibility allow for quick conversion between pattern and cutting lighting by simply replacing one assembly, significantly reducing purchase and transportation costs. This product is suitable for high-end venues such as television stations, theaters, and stages, as well as large-scale concerts and gala performances.


    Technical Specifications

    Category
    Parameter
    Specification
    ​Optical System​
    Light Source
    OSRAM lok-it 1400-PS_Brilliant (High CRI) Lamp

    Reflector
    Italian optical coating process

    Beam Lens Diameter
    140mm

    Total Luminous Flux Output
    > 35,000 lm

    Spot Uniformity
    > 80%

    Zoom Range
    8° ~ 50°

    Color Rendering Index (CRI)
    Ra ≥ 95
    ​Color System​
    Color Mixing
    CMY continuous color mixing

    CTO (Color Temperature Orange)
    Linear adjustment (2700K - 6500K)

    Color Wheel
    7 color filters + White. Bidirectional color rainbow, stepping gradients, bidirectional rotation, random color modes.
    ​Gobo System​
    Gobo Specifications
    Outer Ø: 37.3mm, Thickness: 1.1mm, Pattern Area: Ø26mm, Material: Glass

    Rotating Gobo Wheel
    1 wheel with 5 indexable rotating gobos. Effects: rotation, animation, shake.

    Effects Wheel
    1 dynamic wheel (can be switched in/out, bidirectional rotation). Optional: replace with fixed gobo wheel (9 patterns).
    ​Shutter / Cut System​
    Shutter System
    Full graphic shutter system + 90° graphic positioning


    Shutter blades with precise indexing
    ​Effects​
    Prism
    1 rotating 4-facet prism, bidirectional rotation

    Frost / Diffusion
    Independent frost effect

    Dimmer
    Independent dimmer, 0-100% linear

    Strobe
    Independent strobe, 1-13 flashes/sec. Pulse, asynchronous, synchronous, random (slow/med/fast) modes.

    Iris
    Fast motorized iris, 5-100% linear adjustment with macro effects

    Electronic Frost
    Electronic linear frost via motorized focus, constant beam angle adjustment
    ​Movement (Pan/Tilt)​
    Pan
    540°, precision 2.11°/step, micro-precision 0.008°

    Tilt
    270°, precision 1.05°/step, micro-precision 0.004°

    Positioning System
    Non-contact magnetic rotary encoders for Pan and Tilt
    ​Control & Programming​
    Control Channels
    32 (Standard) / 35 (16Bit) / 42 (Extended)

    Control Protocol
    DMX512, Art-Net, Wireless DMX (Optional)

    Menu Display
    3.5-inch LCD, 128x64 resolution, Chinese/English, 180° invertible display

    Control Method
    Contactless scroll wheel
    ​Electronic Features​
    Backup Power
    Self-charging buffer battery for menu operation when power is off

    Energy Saving
    Automatic power reduction when shuttered or CMY closed

    Fan Control
    Intelligent speed regulation

    Temperature Control
    Electronic temperature sensing

    DMX Monitor
    DMX channel level monitoring

    Info Query
    Fixture information query via LCD screen

    RDM
    Supports bidirectional RDM data transmission

    Positioning
    Magnetic encoders, signal feedback, absolute position memory, DMX/Offline position restore
    ​Power Supply​
    Input Voltage
    200-240V~, 50/60Hz

    Ballast
    Electronic ballast

    Power Consumption
    1800W

    Power Factor
    PF ≥ 0.98
    ​Dimensions & Weight​
    Fixture Dimensions
    465 x 439 x 777.5 mm

    Case Dimensions (Flight Case)
    654 x 524 x 819 mm

    Net Weight
    42.5 kg

    Gross Weight
    78 kg
    ​Packing​
    Flight Case
    1 unit per case
    ​Protection Rating​
    IP Rating
    IP20
