93% And 99% Psa Oxygen Plant 30Nm/h Oxygen Generator For Industrial
Product Principle
PSA ( Pressure Swing Adsorption) technology is a revolution in Non Cryogenic Air Separation and Oxygen Generation technology uses special grade of ZMS ( Zeolite Molecular Sieve).
The compressed air is passed through a twin tower PSA module interconnected with automatic change over valves. After passing through a refrigerated dryer air gets dried. Dried compressed air will now come in contact with bed of zeolite molecular sieves (ZMS). Zeolite Molecular Sieves are special grade of adsorbent which have the property of preferential adsorption of nitrogen molecules. At a time one tower remains under nitrogen production cycle, whereas the other tower undergoes regeneration which is achieved through depressurization of the tower to atmospheric pressure. The outgoing oxygen gas is sent to a surge vessel where the minimum pressure will be maintained with the help of back pressure regulator.
Product Parameters
| Air compressor | Air storage tank | Air Dryer | Oxygen buffer tank | Oxygen storage tank | External dimensions(m) | Total weight | Power
KW |
| GAS-7.5P | CG1.2 | GL-10AT | OT-0.2 | OG20 | 6.1×1.5×2.4 | 1600 | 5.5 |
| GAS-7.5P | CG1.2 | GL-10AT | OT-0.2 | OG20 | 6.1×1.5×2.4 | 1800 | 5.5 |
| GA5-7.5P | CG2.4 | GL-10AT | OT-0.6 | OG20 | 6.2×1.5×2.4 | 2100 | 5.5 |
| GA7-7.5P | CG2.4 | GL-20AT | OT-0.6 | OG30 | 6.3×1.7×26 | 2300 | 7.7 |
| GA7-7.5P | CG2.4 | GL-20AT | OT-0.6 | OG30 | 6.4×1.7×2.6 | 2500 | 7.7 |
| GA11-7.5P | CG3.6 | GL-20AT | OT-1.1 | OG50 | 6.5×1.7×3.2 | 3000 | 11.7 |
| GA11-7.5P | CG4 | GL-30AT | OT-1.1 | OG50 | 6.7×1.7×3.2 | 3500 | 11.9 |
| GA11+-7.5P | CG4 | GL-30AT | OT-1.1 | OG50 | 6.7×1.7×3.2 | 3700 | 11.9 |
| GA15-7.5P | CG5.5 | GL-30AT | OT-1.1 | OG50 | 10.5×1.75×3.2 | 3800 | 16 |
| GA15-7.5P | CG5.5 | GL-40AT | OT-1.7 | OG50 | 10.5×1.75×3.2 | 3850 | 16 |
| GA15-7.5P | CG5.5 | GL-40AT | OT-1.7 | OG50 | 10.5×1.75×3.2 | 3900 | 16 |
| GA1S-7.5P | CG5.5 | GL-40AT | OT-1.7 | QGF0 | 10.5×1.75×3.2 | 3950 | 16.5 |
| GA18-7.5P | CG6 | GL-60AT | OT-2.1 | CG50 | 11×1.75×3.2 | 4000 | 20 |
| GA18+-7.5P | CG6 | GL-60AT | OT-2.1 | 0G50 | 11×1.75×3.2 | 4100 | 20 |
| GA22-7.5P | CG6 | GL-60AT | OT-2.1 | OG50 | 11×1.75×3.2 | 4150 | 23.5 |
| GA22-7.5P | CG8 | GL-60AT | OT-2.6 | OG50 | 11.5×1.75×3.2 | 4200 | 23.5 |
| GA22+-7.5P | CG8 | GL-60AT | OT-2.6 | OG50 | 11.5×1.75×3.2 | 4300 | 23.5 |
| GA30-7.5P | CG10 | GL-60AT | OT-2.6 | OG50 | 12×1.75×3.2 | 4500 | 31.5 |
| GA30-7.5P | CG10 | GL-80AT | OT-3 | OG50 | 11.5×1.75×3.2 | 4600 | 31.5 |
| GA30-7.5P | CG10 | GL-80AT | OT-3 | OG50 | 11.5×1.75×3.2 | 4650 | 31.5 |
| GA30+-7.5P | CG12 | GL-80AT | OT-3 | OG50 | 11.5×1.75×3.2 | 4900 | 31.5 |
| GA30+-7.5P | CG12 | GL-80AT | OT-3 | OG50 | 12.5x1.75x3.2 | 5000 | 31.5 |
| GA30+-7.5P | CG12 | GL-80AT | OT-3.6 | OG60 | 12.8x1.75x3.25 | 5200 | 31.5 |
| GA30+-7.5P | CG15 | GL-100AT | OT-3.6 | OG60 | 12.9x1.75x3.25 | 5300 | 32.5 |
| GA30+-7.5P | CG15 | GL-100AT | OT-3.6 | OG60 | 12.9x1.75x3.25 | 5350 | 32.5 |
| GA30+-7.5P | CG15 | GL-100AT | OT-4 | OG60 | 13x1.75x3.25 | 5400 | 32.5 |
| GA37-7.5P | CG15 | GL-100AT | OT-4 | OG60 | 13.8x1.75x3.25 | 5450 | 39.5 |
| GA37-7.5P | CG15 | GL-100AT | OT-4 | OG60 | 13.8x1.75x3.25 | 5500 | 39.5 |
| GA37-7.5P | CG15 | GL-120AT | OT-4.5 | OG60 | 13.85.x19x3.25 | 5550 | 39.7 |
| GA37+-7.5P | CG15 | GL-120AT | OT-4.5 | OG60 | 14.5x1.9x3.25 | 5800 | 39.7 |
| GA37+-7.5P | CG15 | GL-120AT | OT-4.5 | OG60 | 14.5x1.9x3.25 | 5850 | 39.7 |
| GA37+-7.5P | CG15 | GL-120AT | OT-4.8 | OG60 | 14.5x1.9x3.25 | 5800 | 39.7 |
| GA45-7.5P | CG18 | GL-120AT | OT-4.8 | OG60 | 15x1.9x3.25 | 5950 | 47.7 |
| GA45-7.5P | CG18 | GL-120AT | OT-5 | 0060 | 15x1.9x3.25 | 6000 | 47.7 |
| GA45-7.5P | CG18 | GL-120AT | OT-5 | OG60 | 15x1.9x3.25 | 6050 | 47.7 |
| GA45+-7.5P | CG18 | GL-150AT | OT-5 | OG60 | 15.5x1.9x3.25 | 6300 | 48 |
| GA45+-7.5P | CG18 | GL-150AT | OT-5.6 | OG60 | 15.5x1.9x3.25 | 6350 | 48 |
| GA45+-7.5P | CG18 | GL-150AT | OT-5.6 | OG60 | 15.5x1.9x3.25 | 6400 | 48 |
| GA45+-7.5P | CG18 | GL-150AT | OT-5.6 | OG60 | 15.5x1.9x3.25 | 6450 | 48 |
| GA55-7.5P | CG20 | GL-150AT | OT-6 | OG60 | 15.5x1.9x3.25 | 6500 | 58 |
| GA55-7.5P | CG20 | GL-150AT | OT-6 | OG100 | 15.5x2.3x3.35 | 7700 | 58 |
| GA55-7.5P | CG20 | GL-150AT | OT-6 | OG100 | 15.5x2.3x3.35 | 7750 | 58 |
| GA55-7.5P | CG20 | GL-150AT | OT-6.5 | OG100 | 15.5x2.3x3.35 | 7800 | 58 |
| GASS-7.5P | CG20 | GL-150AT | OT-6.5 | OG100 | 15.5x2.3x3.35 | 7850 | 58 |
| GA55-7.5P | CG20 | GL-150AT | OT-6.5 | OG100 | 15.5x2.3x3.35 | 7850 | 58 |
| GA55+-7.5P | CG22 | GL-200AT | OT-6.5 | OG100 | 15.5x2.3x3.35 | 7900 | 59 |
| GA55+-7.5P | CG22 | GL-200AT | OT-7 | OG100 | 15.5x2.3x3.35 | 7900 | 59 |
| GA55+-7.5P | CG25 | GL-200AT | OT-7 | OG100 | 15.5x2.3x3.35 | 8050 | 59 |
| GA75-7.5P | CG25 | GL-200AT | OT-7.5 | OG100 | 15.5x2.3x3.35 | 8200 | 79 |
| GA75-7.5P | CG25 | GL-200AT | OT-7.5 | OG100 | 15.5x2.3x3.35 | 8250 | 79 |
SPARE PARTS
1. Air Compressor (Screw type): Air is used as raw material to collect & compress air to 8 bar.
2. Refrigerated Dryer: The standard configuration removes moisture and impurities in the air, so that the air dew point reaches -20°C (the intermediate configuration uses an adsorption dryer, and the dew point reaches -40°C; the advanced configuration uses a combined dryer, and the dew point reaches- 60ºC).
3. Precision Filter: A/T/C three-stage filter to remove oil, dust and impurities.
4. Air buffer Tank: store pure and dry air for subsequent adsorption and separation of oxygen as raw material storage.
5. Adsorption Tower: A&B adsorption tower can work alternately, regenerating adsorption, filling sodium molecular sieve to filter out oxygen molecules.
6. Oxygen Analyzer: real-time monitoring and analysis of oxygen purity, indicating that the equipment is working normally and alarming.
7. Valves & Pipelines: Intelligent control valves realize automatic operation of equipment, PLC control, SUS304 pipelines.
8. Oxygen Buffer Tank: Store oxygen with qualified purity, which can be directly piped or used for bottle filling.
9. Oxygen Booster: Gas booster, pressurize the oxygen to the filling pressure, generally 150bar or 200bar.
10. Filling Manifold: split high-pressure oxygen & nitrogen into each gas cylinder
| Packaging |
| Size | 123 (L) * 456 (W) * 789 (D) |
| Weight | 1.2 T |
| Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
In addition to PSA Oxygen Generators, we also produce VPSA Oxygen Generators, storage tanks, heat exchangers and other products. If you are interested in VPSA Oxygen Systems or other products, please feel free to send an email to info@gneeheatex.com. We will be very happy to serve you.
