300km IP Uhf Mesh Radio System Network Link 20W RF 128bit Encryption

IP Mesh Radio Link With 20W RF Power And 300km Long Range Data Transmission

Key Features:

• Supports up to 735kbps wireless link rate.
• Supports Point-to-Point, Point-to-Multipoint, Multipoint-to-Point and Mesh topologies.
• Supports maximum 1024 nodes mesh network.
• High sensitivity: -114 dBm when data rate is 125kHz.
• Supports frequency hopping(FHSS).
• Air-to-ground LOS(light of sight) distance: ≥300km,ground-to-ground LOS range 3~10km.
• Two serial ports (TTL/RS232/RS422 optional).

Mesh Radio Overview:

• The Mesh radio enables decentralized and long-distance communication among a large number of nodes. All nodes can communicate independently without interfering with each other.
• Support large-scale dense node access to wireless transmission, dynamic networking and flexible reorganization.
• Support full-multiplexing communication,the node can send data while also receiving data from all other nodes, and there is no mutual interference.
• And in the case of absence of the center, it can achieve interoperability between any node and all other nodes in the network without mutual interference.
• In the absence of a central node, it is capable of establishing connections between any node in the network and all other nodes.

Application of the Mesh Radio:

Our Mesh radio device are mostly used in swarming drones, Internet of Things, UAV data link, remote control, data collection, artificial intelligence, military equipment, etc.

HNC2 20W data link mesh radio models:

Technical Specifications:

Input/ Output
