    Intelligent Home Appliance Digital Bench Scale for IoT RS232 485 Bluetooth 4G Nonlinear 0.01%FS 5.5-12VDC 1g Accuracy

    Ask Lasest Price
    Price : $5.50/pieces 10-1999 pieces
    Brand Name : OEM
    Certification : ISO,CE,ROHS,FCC,OIML
    Model Number : OEM
    Delivery Time : 5-8 business days
    Payment Terms : T/T,Western Union
    Supply Ability : 100 pieces per day
    • Product Details
    • Company Profile

    Intelligent Home Appliance Digital Bench Scale for IoT RS232 485 Bluetooth 4G Nonlinear 0.01%FS 5.5-12VDC 1g Accuracy


    High Precision Electronic Platform Scale Weight Module RS232 Communication TTL Seismic Anti-interference Pressure Module
    Product Overview
    BT559A Digital Weighing Module
    The BT559A weighing module is made of highly integrated circuits and can convert weak weighing signals into standard digital signals, which are sent to other central control units through the RS232 interface. It is a cost-effective product designed specifically for the weighing needs of smart home appliances.
    Product Features
    1. Turn on/off, weigh and read values;
    2. Peeling, zeroing, and calibration;
    3. Start up and reset/not reset;
    4. Range accuracy setting, 232/TTL telecommunications
    5. Anti static interference and anti signal interference;
    6.Weight warning prompt ,digital signal;
    7. ID can be set;
    Specification parameters




    Power supply:
    3V or 4.5-12V

    Communication interface:
    RS232 9600/n/8/1
    Working temperature:
    -20-50 ℃

    Protocol:
    Add parameter reading function and write unlocking function
    Maximum temperature:
    90% R.H

    Non condensation Non linearity:
    0.01% F.S
    Power consumption:
    about 10, MW (including sensor)

    Gain drift:
    100ppM/℃
    PCB physical size:
    length 60 * width 50 * height 3mm

    A/D resolution:
    1/200000
    Zero adjustment range:
    -0.3-0.3mV

    Maximum measurement accuracy:
    1/100000
    Input range:
    -5mV-5mV

    Power supply protection:
    Power supply reverse connection protection
    A/D conversion speed:
    16/s

    filtering:
    multi-level digital filtering, with seismic interference function;

    The weighing problem we can solve

    1. Unstable readings, jumps, and inaccurate weighing
    2. Creep caused by long-term load and unreliable data
    3. Unstable serial port, occasional inability to read data, garbled code, and parameter modification
    4. High accuracy, unstable, low accuracy, stable but not sufficient
    5. Insufficient applications, functions, and adjustable parameters, unable to meet application requirements
    Your trouble is our profession! “
