| Brand Name : | RGH |
| Model Number : | RT235QV007A |
| Certification : | ISO9001/ISO14001 |
| Price : | Negotiable |
| Payment Terms : | L/C, T/T,Paypal |
| Supply Ability : | 3.5kk |
| Delivery Time : | 3-5weeks |



| NO. | Symbol | Level | Function |
| 1 | LEDAl | LED power anode | |
| 2 | LEDK | LED power cathode | |
| 3 | GND | Ground | |
| 4 | RESET | Reset pin | |
| 5 | VS | Frame synchronizing signal for RGB interface operation | |
| 6 | HS | Line synchronizing signal for RGB interface operation | |
| 7 | DCLK | Dot clock signal for RGB interface operation | |
| 8 | DE | Data enable signal for RGB interface operation | |
| 9 | GND | Ground | |
| 10-14 | R4-R0 | data bus | |
| 15-20 | G5-G0 | data bus | |
| 21-25 | B4-B0 | data bus | |
| 26 | IOVCC | Power setting | |
| 27 | SDI | Serial data inputloutput bidirectional pin for SPI Interface. | |
| 28 | SDL | Serial clock input for SPI interface. | |
| 29 | CS | chip select signal | |
| 30 | VCC | Power setting |
![]() | ![]() |




FAQ
1: What are the payment terms?
A: We usually accept T/T, Paypal, other terms to be negotiated.
2: What’s the lead time?
A: Usually 3~5 days for sample orders if goods are in stock, and
3~5 weeks for mass production (basing on the quantity and product).
3. Do you support custom logo on the CTP?
A: Yes, we support, pls send us your detail inquiry, our sales will contact you asap.
4. How can I place a sample order?
A: Pls send us your inquiry, our sales will contact you soon.
5. What size LCD display can you provide?
A: 0.96 inch to 20 inch TFT LCD display we can provide.
7. What's your MOQ?
A: Most of our product's MOQ is 1K, beacuse we are a LCD display manufacturer.
8. What shipping ways do you support?
A: We can consult with it.
|
