Full-Automatic Custom 500-20000l/H UHT Sterilizer For Different
Types Of Liquid Products Milk/Juice/Sauce SUS304/316
Download to learn more
tubular sterilizer production introduce.pdf
Click to learn more
https://www.youtube.com/watch?v=6MGcJ049e6o&list=PLMqO7-CTBpXtUf9nzvIHNa66uz3jZ9MOI&index=6
UHT Sterilizer Overview:
The fully automated custom (Ultra High Temperature)UHT Sterilizer
is a cutting-edge solution designed for efficient, reliable
sterilization of a wide range of liquid products. UHT Sterilizer
With a processing capacity of 500 to 20,000 liters per hour, this
high-performance system is ideally suited for large-scale
production environments.
UHT Sterilizer Main features:
Advanced sterilization technology: Using UHT sterilization
technology, the liquid is quickly heated to a high temperature
(usually 135-150°C) in a very short period of time, and then
quickly cooled to ensure complete inactivation of microorganisms.
Customizable Design: Tailor-made to meet the specific requirements
of different liquid products including milk, juices and sauces.
Adapt to various production scales and processing needs.
Fully automatic:UHT Sterilizer Equipped with advanced control
system to realize automation of the entire sterilization process.
This includes temperature control, pressure monitoring and timing
to ensure consistent quality and minimize human intervention.
HIGH QUALITY MATERIAL: Made of SUS304 and SUS316 stainless steel,
known for its excellent corrosion resistance and durability. These
materials ensure long-term performance and meet food safety
standards.
Efficient heat exchange:UHT Sterilizer Use advanced heat exchange
technology to optimize thermal efficiency and reduce energy
consumption. The design minimizes heat loss and ensures efficient
heat treatment.
User-friendly interface: Equipped with an intuitive touch screen
control panel for easy operation and monitoring. Provides real-time
data and alerts to help maintain optimal operating conditions.
Hygienic Design: UHT Sterilizer Design focused on hygiene and ease
of cleaning. Features such as a CIP (Clean in Place) system are
included to ensure the entire system is cleaned thoroughly and
efficiently.
Versatility:UHT Sterilizer Suitable for a variety of liquid
products, adaptable to different viscosities and formulations.
Ideal for use in the dairy, beverage and food processing
industries.
UHT Sterilizer application
| Typical application | Mango pulp | Coconut water | UHT milk | Fruit juice |
| Flow | 1000l/h | 3000l/h | 5000l/h | 8000l/h |
| Power | 13 | 11 | 12 | 20 |
| Temperature in | 40 | 4 | 4 | 55 |
| Sterilizing temperature | 108 | 80/ 140 | 137 | 125 |
| Holding time | 120 | 90 /8 | 5 | 15 |
| Temperature out | 40 | 10/35 | 25 | 85 |
| Note | The flow and temperature could tailor-made as per project demand
from 500-20,000L/h |
UHT Sterilizer Benefits:
Enhanced Product Safety: Ensures effective microbial elimination,
extending shelf life and maintaining product safety.
Operational Efficiency: Streamlines the sterilization process with
minimal manual intervention, reducing labor costs and human error.
Energy Savings: Optimizes energy usage through advanced heat
exchange technology.
UHT Sterilizer Applications:
Dairy Industry: For sterilizing milk and cream.
Beverage Industry: Suitable for fruit juices, flavored drinks, and
other liquid beverages.
Food Processing: Ideal for sauces, soups, and other liquid food
products.
