2930F JL255A 24 Port PoE+ Layer 3 Managed Switch with 10GbE Uplinks
original new in stock
Product Overview
The Aruba 2930F 24G PoE+ 4SFP+ Switch (model JL255A) is a high
performance Layer 3 managed network switch designed for enterprise
edge, branch offices, and SMB environments. Featuring 24 Gigabit
PoE+ ports and 4 SFP+ uplinks with up to 370 W PoE power, this
switch delivers robust throughput, advanced routing, and seamless
stacking with Virtual Switching Framework (VSF). Ideal for powering
IP cameras, wireless access points, and surveillance devices, it
supports scalable, secure, zero touch deployment and unified
wired-wireless management.
Product Details
| Item | Description |
|---|
| Port Configuration | 24 x autosensing 10/100/1000 PoE+ ports + 4 x SFP+ (1/10 GbE)
uplinks |
| PoE Budget | 370 W (PoE+) |
| Layer 3 Features | Static routing, RIP, Access OSPF, ACLs, IPv6, QoS, VSF stacking, no
licensing required |
| Management Tools | Aruba ClearPass, Aruba AirWave, Aruba Central, CLI, REST API,
OpenFlow |
| Throughput & Capacity | 95.2 Mpps forwarding, 128 Gbps switching capacity |
| Additional Features | Zero Touch Provisioning, SDN support, robust security controls |
Key Features
• 24 Gigabit PoE+ ports with 370 W power budget
• 4 x 1/10 GbE SFP+ uplinks for high speed connectivity
• Layer 3 routing including OSPF, RIP, ACLs, IPv6 without extra
licensing
• Stacking support via VSF (up to 8 members)
• Unified management: ClearPass, AirWave, Aruba Central, REST API,
OpenFlow
• Zero Touch Provisioning for fast deployment
• High performance: 95.2 Mpps, 128 Gbps backplane
Product Specification Table
| Specification | Details |
|---|
| Ports | 24 RJ-45 10/100/1000 PoE+ ports (IEEE 802.3at) + 4 SFP+ (1/10 GbE)
slots |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 95.2 Mpps |
| MAC Address Table | 32768 entries |
| Processor & Memory | Dual core ARM Cortex A9 ~1.016 GHz, 1 GB DDR3, 4 GB eMMC |
| Latency | < 3.8 µs (1 GbE), < 1.6 µs (10 GbE) |
| Power Budget & Consumption | 370 W PoE+, max ~445 W, idle ~36.8 W |
| Dimensions | 44.25 cm x 30.42 cm x 4.39 cm (1U height) |
| Operating Environment | 0°C to 45°C, 15%–95% RH non condensing |
| Stacking Support | VSF stacking up to 8 members |
Similar Models Comparison Table
| Model | Key Differences |
|---|
| JL253A | Same port count, no PoE support |
| JL254A | 48 RJ-45 ports, no PoE |
| JL256A | 48 PoE+ ports, larger capacity |
| JL258A | Smaller 8 port PoE+ variant |
Latest Model in Same Series
| Model | Notable Upgrades |
|---|
| JL256A | Expanded to 48 PoE+ ports, double the port density while retaining
4 SFP+ uplinks, ideal for larger network deployments |
