6ES7338-4BC01-0AB0 SIEMENS SIMATIC S7-300, Signal Module

SIEMENS 6ES7338-4BC01-0AB0 SIMATIC S7-300, Signal Module :

SIMATIC S7-300, Signal module for 3 SSI encoders for reading in the position value with 2 FREEZE inputs, 1x 20-pole Supports isochronous mode.

The 6ES7338-4BC01-0AB0 is a SM 338 position input module from Siemens' SIMATIC S7-300 series, designed for precise position detection in industrial automation. This module supports three SSI (Synchronous Serial Interface) encoders, providing 13-bit resolution positioning data with two FREEZE input terminals for value locking. It integrates clock synchronization and is housed in a compact form factor (40 mm width, 125 mm height). The module connects via a 20-pin front connector and is suitable for applications requiring dynamic position feedback, such as CNC machines, automated assembly lines, and industrial robots.

Technical Specifications:

Product Series: SIMATIC S7-300 SM 338 Position Input Module

Encoder Support: 3x SSI encoders, 13-bit resolution

Input Ranges:

Voltage: 0–10 V (selectable)

Current: 4–20 mA (selectable)

Input Delay: 300 μs (at nominal voltage)

Power Supply: 24 V DC (L+: 100 mA; Backplane: 160 mA)

Sensor Power: 24 V DC, 900 mA output

Power Loss: 3 W (typical)

Connection: 20-pin front connector, shielded encoder wires (max. 320 m @ 125 kHz)

Diagnostic Features: Alarm reporting, non-isolated

Configuration: STEP 7 software for parameterization (encoder type, data format, transmission rate)

Environmental: -20°C to 60°C operating temperature, RoHS compliant

Physical Dimensions: 40 mm (W) × 125 mm (H) × 120 mm (D), 235 g weight

Application Areas: High-precision position control in machinery, robotics, and process automation.
