40G QSFP+ LX4 2km Transceiver Fiber Optic Transceiver Module

• 4 CWDM lanes MUX/DEMUX design
• Transmission data rate up to 11.3Gbps per channel
• SMF LC duplex connector
• Hot Pluggable QSFP+ form factor
• Up to 2km SMF or 150m om4 MMF transmission
• Compatible with RoHS
• Single +3.3V power supply
• Real Time Digital Diagnostic Monitoring
• Operating case temperature: 0 to +70°C

Applications

• 40GBASE-LX4 Ethernet
• Infiniband QDR and DDR interconnects
• Client-side 40G Datacom connections

• QSFP MSA
• SFF-8436
• IEEE 802.3ba

Description

• The MJ1N-LXT8 transceivers are high performance, cost effective modules supporting data rate of 40Gbps and 2km transmission distance with SMF or 100m om4 MMF. The transceiver consists of three sections: 4 inputs channels (ch) of 10Gb/s electrical data to 4 CWDM optical signals, and multiplexes them into a single chan- nel for 40Gb/s optical transmission; on the receiver side, the module optically de-multiplexes a 40Gb/s input into 4 CWDM channels signals, and converts them to 4 channel output electrical data; and MCU control unit. All modules satisfy class I laser safety requirements.
