    Wood Mould Five Axis Machining Center Glass Fiber Replacement

    Ask Lasest Price
    Brand Name : SUBA
    Model Number : 4060
    Certification : CE
    Price : bargaining
    Payment Terms : T/T
    Supply Ability : 100 set
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Wood Mould Five Axis Machining Center Glass Fiber Replacement

    Wood mold five-axis machining center glass fiber replacement glass fiber

    Product introduction:

    The speed master wood mold processing center adopts a bridge-type beam drive mode, and the Y-axis walking track adopts a frame.
    The frame structure can better ensure the precision and speed of equipment processing. According to the comparison of market customer usage, its comprehensive
    The processing efficiency is 3 times higher than that of the gantry type machining center, and it is currently the preferred product for CNC machining equipment for non-metallic molds.
    The overall bed of the machine is welded with steel plate, and there are reinforcements inside the gantry beam. After annealing treatment, the machine tool's rigidity is ensured.
    Sex and stability, better to withstand the rigidity of the machine tool running at high speed.
    It can be used for intelligent processing of composite materials such as wood, foam, substitute wood, resin, carbon fiber, etc.; suitable for lost foam, wood
    The use of molds, luggage molds, new energy, aerospace and other industries.


    Parameter

    Model

    STM4060-5A

    Movement type

    Movable gantry

    Working area(MM)

    4000*6000*1200

    Output power of Spindle

    24-29KW

    Spindle speed

    24000 RPM/min

    Servo system

    YASKAVA Servo system

    Inverter

    Delta inverter

    Table size (MM)

    4000*6000mm

    Material of Table

    Aluminum Profile

    Tool magazine

    Rotary tool magazine (8 positions)

    Cutter specifications

    HSK F63

    Programming Software

    AlphaCAM

    Total Power(KW)

    50KW

    Voltage

    AC 3P 380V 50HZ

    Efficiency File Conversion(hr/day)

    0.5

    Equipment data storage and capacity

    Cable transmission, USB, CF
