Screw Conveyor

Product description
U-shaped screw conveyor is very important in the field of industrial production and material handling, its main body is U-shaped channel, made of solid metal, can adapt to particles, powder, small blocks and other materials. The spiral blade in the groove is tightly around the central shaft, like a mechanical dragon. With the central shaft rotating under the stable and adjustable power provided by the driving device (including the motor and the reducer) at one end, the material is pushed forward efficiently and stably by the spiral propulsion method to avoid accumulation and blockage. It has a simple and compact structure, small footprint, easy installation and maintenance, and can flexibly adapt to different production environments. It is widely used in food processing, chemical industry, building materials and other industries, and is a key link to ensure the smooth transportation of materials and connect the production process.

Working principle
When the U-screw conveyor is working, the motor in the drive device starts, converts electrical energy into mechanical energy, adjusts the speed through the reducer, and outputs stable and adaptive power to the central shaft. The central shaft drives the spiral blade tightly around it to rotate in the U-shaped groove. The material enters the U-shaped groove from the feed port. During the rotation of the spiral blade, the spiral surface constantly exerts the thrust along the tangent direction of the spiral line on the material. Due to the obstruction of the U-shaped slot, the material cannot move in a circle with the spiral blade. It can only move in a straight line from the feed end to the discharge end along the axial direction of the U-shaped slot under the action of the axial component of the thrust, and finally output from the discharge port to realize the efficient and continuous conveying process of the material.

Product characteristics
1. Simple and compact structure: U-shaped screw conveyor is mainly composed of U-shaped groove, spiral blade, central shaft and drive device, and the number of parts is small. The overall layout is compact, takes up little space, and can be flexibly installed and arranged in a working environment with limited space.

2. Stable and efficient conveying: relying on the unique design and operation mode of spiral blades, it can achieve stable, efficient and continuous conveying of materials. In the conveying process, the damage degree to the material is minimal, and the original characteristics of the material can be effectively maintained.

3. Suitable for a wide range of materials: whether it is a granular material with good fluidity, or a powder material that is easy to gather, or a small block material, the U-shaped screw conveyor can accurately push to meet the transportation needs of different materials.

4. Strong industry adaptability: suitable for many industries such as food, chemical, building materials, etc., can adapt to the conveying conditions of materials in different industries, and play a role in diversified production scenarios.

5. Adjustable transmission parameters: By adjusting the speed of the drive device, the transmission speed and throughput can be flexibly changed, which can be accurately regulated according to the actual production needs to meet the requirements of diversified production conditions.

6. Easy maintenance: the equipment runs smoothly and the noise is low. Daily maintenance work is simple, only periodically check the wear of the spiral blade, the connection status of the central shaft and the operating status of the drive device, you can ensure the long-term stable operation of the equipment, effectively reduce the cost of equipment operation and maintenance.

Product parameter

Product details


Application

Packaging & Shipping

Why Choose US




About us


We have been specializing in the production of Screening and conveying equipment for 13 years. China's vibrating screen industry top three. And we have done matching and OEM for many large companies. Including the world's top vibrating screen manufacturer, Sweco, USA, we have OEM
for his China region. And our products are often exported to Australia, Thailand, Indonesia, New Zealand and other countries.

We welcome customers or dealers to visit our factory and will arrange everything for you.Our factory address: West of the industrial and commercial office of Da Zhaoying Town, Xinxiang City, Henan Province.

Who are we:

EVERSUN Machinery, founded in 2003, is a professional manufacturer of screening and conveying equipment in China. It is also iso9001:2015 quality management system certification and CE certification company.

Eversun Machinery is committed to providing screening and conveying technology solutions to our customers. Whether you are in food, chemical, pharmaceutical or other industries, whether you want to separate solid particles from solid or liquid, we will provide screening and transportation solutions according to the characteristics of different industries and materials to meet the requirements of customers. And improve efficiency and product quality.

For screening and conveying solutions, please contact us at.

What do we produce:

Our products include: screening machine, drum screening machine, ultrasonic vibrating screen, liquid filter, linear screening machine, vacuum conveyor, dumping station, grinder, etc.

And can customize various machines.

Our services:

EVERSUN Yongsheng Machinery has the ability to serve customers all over the world, whether it is on-site maintenance, installation and commissioning, or after-sales accessories. And any electrical and safety standards. Our price and delivery ability have also been highly praised by customers

Professional OEM factory:

As one of the largest OEM factories in China, we provide about 5000 machines to more than 150 dealers, manufacturers and traders every year, and provide a variety of reliable customized equipment to help our customers build their own brands.
