Multi-function Keystroke Testing Machine 3 Points / 4 Points Test With Servo Control

Servo Control Multi-function Keystroke Testing Machine 3points / 4points Test

Model: RS-6900A

Application:

This servo control Multi-function tester is suitable for the keystoke testing, the compression for product outer shell and LCD screen, the testing of optional 3 points bending, 4points bending. This tester can make the operational platform to work in the expected track by the movement controller, electrical motor and moving platform; the test software can automatically collect the data of load vs displacement, and create Load vs displacement curve accordingly, automatically save the testing data and automatically judge Pass or Failure.

Specialties:

1. The X-Y coordinate for testing the specimen can be manually selected in the computer software or directly input the AUTOCAD file in the system to get the coordinate . Can save the tested movement track and call to use next time, the data saving has no limit. These increase the testing efficiency and the accuracy of the coordinate.

2. Z axis is controlled by Micro measuring controller; collecting the data of the load on key by precise load cell made by U.S. TRANSCELL. This testing machine adopts high rigid steel as structure, and the surface treatment is with surface polishing and chromium electroplated.

3. X,Y,Z axis adopt servo motor from Japanese Panasonic to drive; transmission by precise ballscrew which can achieve the low noise and long durability.

Typical Application:

1. Can do the multi-points compression testing for product outer shell, LCD screen, and whole unit( can set the several tested points to be the coordinate, and it can auto test according to the coordinate, can set the compression load, compression time).

2. Can do the key stoke multi-point curve testing,

3. Can do the 3points bending, and 4points bending testing, the testing is controlled by software.

Technical parameters:

Picture:

Infinity Machine International Inc. was founded in 1998.

The company headquarters is located in Dongguan city Guandong province.

In 19 years, we have been focused on products’ reliability test and automated test machine and specializing in developing, production, marketing and maintenance of all kinds of testing machines.

We’ve widely received favorable response from our customers, and we became core supplier of famous brands in succession, including AMAZON, GOOGLE, INTEL, FOXCONN, LITEON, ZTE, OPPO, TCL, GREE and SONY, etc. Our equipment is also sold throughout the world, to Europe, The Middle East, South America, North America and Southeast Asia and so on.

In order to meet the market demand, Infinity Machine has Registered a logo:

Our products are used in such fields as testing machines for mechanics; weather withstanding of diverse materials; package testing; furniture testing; electronic and electrical product testing; tape and rubber testing; shoes and leather product testing; reliability testing for IT digital products (such as mobile phones, notebook, and computer accessories).

We aspire to become the world’s top testing machine R&D and manufacturing company, to provide the world testing technology and programs with maximum performance; to provide top-quality testing machines and services; and to make remarkable contributions to human modernization; to provide most accurate and front-end testing machines to China’s manufacturing, and make it our mission to improve quality of national manufacturing industry.

Our commitment is "Top quality products and perfect services for customers".

Customers are warmly welcomed to choose us to be their supplier of lab testing machine.

Our company looks forward to cooperating with you, and strive to provide perfect service for you!
