Verify the board connector footprint and pinout before production to ensure full compatibility with the PCB header.
Confirm that total drive current is within the rating of the wire gauge, connector and power rail.
Avoid tight bends or twisting of the flat SATA ribbon, especially near the overmolded sections, to protect signal integrity.
Keep data and power harnesses away from strong EMI sources where possible.
Ensure both connectors are fully inserted and locked; inspect periodically for damaged insulation, loose terminals or signs of overheating in high-duty applications.
