Efficient Goods Classification Swivel Wheel Sorter Minimizes Goods
Damage During Handling
The Swivel Wheel Sorting Machine, often referred to as the Divert Wheel Sorter or Rotating Wheel
Sorter, is a state-of-the-art solution designed for the efficient
sorting of parcels and cartons in conveyor systems.
This machine integrates an electric drum (wheel), a steering
mechanism, a control unit, and a robust frame. It operates by
rotating the electric drum to move items, with servo motors and
steering modules adjusting the drum's angle to divert items left or
right. The Swivel Wheel Sorting Machine can handle various
packaging types, including cartons up to 50kg, waterproof bags,
woven bags, and flat-bottomed non-standard packages. With a sorting
speed of 2m/s, it can process up to 6000 items per hour, making it
perfect for applications in postal services, express delivery,
e-commerce logistics, and distribution centers.
For further information about the Swivel Wheel Sorting Machine,
please consult the product description below or contact our
customer service representatives at Realkey.
Product Features
Technical Parameters
| Model | SWS-10M | SWS-12H |
| Sorted Items | Medium to large parcels, woven bags, flexible packages, etc. |
| Weight Range | 0.2kg≤M≤50kg | 0.2kg≤M≤50kg |
| Sorting Capacity | 4000 pieces per hour | 6000 pieces per hour |
| Parcel Size Range | MAX:1000*1000*700mm |
| (Example for a 1-meter wide device) | MIN:150*150*30mm |
| Sorting Success Rate | 99.99% |
| Sorting Modes | Single-sided sorting / Double-sided sorting |
| Electric Drum Size | Drum length 85mm * Drum diameter 70mm |
| Conveying Speed | 1-1.5m/s | 1.2-2m/s |
| Number of Swing Mechanisms | Not less than 2 | Not less than 5 |
| Parcel Spacing | 800mm | 400mm |
| Operating Noise | ≤72dB(A) |
Product Features
Versatility
The swivel wheel sorter is equipped with a flat surface made of
numerous small electric rollers coated in rubber. This design
ensures a broad area of flexible contact with items, providing a
smooth and effective sorting process. It is particularly adept at
handling a wide range of parcels, including clothing, books, boxes,
and cartons.
Efficient Sorting
Employing electric rollers as its primary conveying medium, the
swivel wheel sorter offers significant advantages such as high load
capacity, low noise, rapid operation, and smooth transmission. By
streamlining traditional systems, this sorter enhances operational
efficiency, achieving sorting speeds of up to 6000 pieces per hour.
Compact Structure
The swivel wheel sorter features a simple yet effective design,
resulting in a stable structure with a low failure rate. The
steering mechanisms are connected through articulated bearings,
allowing for precise adjustments to steering angles based on actual
usage. Servo motors provide quick and responsive steering, while
multiple independently controlled steering modules operate
efficiently with minimal sorting signals.
Quick Installation and Removal
The single-group swing wheel and single-row module of the swivel
wheel sorter are designed with modularity in mind. Independent
conveying units can be easily disassembled from the transmission
components, allowing for rapid assembly and straightforward
maintenance.
Application
The swivel wheel sorter excels in delivering a seamless sorting
experience, making it suitable for various parcel types, including
clothing, books, boxes, and soft packages.
It is widely utilized in logistics environments such as express
delivery services, logistics centers, and warehouses, where it can
swiftly and accurately sort express parcels and other goods.
In e-commerce warehouses, the swivel wheel sorter significantly
enhances operational efficiency by enabling rapid processing of
high volumes of orders and parcels, making it an invaluable asset
in e-commerce logistics.
In manufacturing environments, this sorter aids in effectively
managing raw materials, components, and other items, ensuring
proper categorization and storage. It is commonly employed in
sectors such as healthcare, food processing, and renewable energy.
Advantages
Advanced Technology
The Realkey swivel wheel sorter features an advanced control system that, along
with integrated sensors, efficiently manages the start and stop
functions based on package arrivals, ensuring high efficiency and
energy savings. The servo-driven sorting mechanism allows for rapid
response times and precise control over turning angles, with
various sorting modes—uni-directional, bi-directional, and
multi-angle—tailored to specific application needs.
Precision Manufacturing
Components are produced using CNC precision machining, ensuring
meticulous assembly and adherence to high-quality standards. This
commitment to detail results in equipment characterized by high
precision, long lifespan, low noise levels, and minimal maintenance
costs.
Safety and Stability
The Realkey swivel wheel sorter is constructed for durability, providing high
reliability and stability that meet advanced industry standards.
Comprehensive safety features are integrated throughout the system,
ensuring a secure working environment for operators.
Reliability
With 17 years of experience in logistics automation and sorting
solutions, Realkey has established a strong reputation for delivering effective
sorting strategies. Our products are renowned for their exceptional
durability, making Realkey a trusted partner in the logistics industry.
