    Low Noise Mems Gyro Sensor For Remote Control Helicopters

    Ask Lasest Price
    Brand Name : RION
    Model Number : TL618D
    Certification : CE, FCC,ROHS , ISO
    Price : US$245~US$460
    Supply Ability : 30000pcs per month
    Delivery Time : 1-2 weeks
    • Product Details
    • Company Profile

    Low Noise Mems Gyro Sensor For Remote Control Helicopters

    TL618D MEMS Current Electronic Gyroscope Sensor For Remote Control Helicopters


    KEY FEATURES

    ★ High performance drift stability

    ★ Low noise

    ★ Light weight

    ★ Long life,strong stability

    ★ Cost-effective

    ★ Excellent vibration performance

    ★ All solid state

    ★ Compact & light design

    ★ 4-20mA Current output

    ★ Wide temperature range

    ★ DC+9~36V power supply

    ★ Temperature drift< ±0.1°/sec/℃


    APPLICATION

    ★ Navigation

    ★ Car navigation

    ★ 3D virtual reality
    ★ Platform stability

    ★ Auto safety system
    ★ Turck-mounted satellite antenna equipment

    ★ Industrial control

    ★ Equipments

    ★ GPS combination

    ★ Camera stability

    ★ Robot

    ★ Ships electronic needle error compensation on inclined(angle rate) induction equipment


    GENERAL DESCRIPTION

    TL618D is a gyroscope (angle rate sensor) based on the micro mechanical principle, a miniature inertial devices for mainly measuring the angular velocity of a moving object. Product internal with the silicon ultrafine precision ring sensing technology so that it has a high-performance, waterproof,anti-vibration, light weight, anti-electromagnetic interference characteristics and etc. Uninterrupted the machine with self-test technology, the filtering algorithm and the first time in the country by eliminating resonance technology to solve the influence on data because of the surrounding noise or vibration interference source to the ordinary gyroscope. TL618D add another international temperature sensor ompensation technology to solve the temperature drift impact problems,with over-temperature stability and long life characteristics etc. to realize the domestic similar products technology-leading technology.

    Products with high cost-effective, small volume , is now widely used in the automotive, marine, moving objects, position control & attitude control, and other applications that require precise angle measurement occasions !


    TECHNICAL DATA

    TL618DPARAMETERS
    Measurie range±50°/s±150°/s±300°/s
    Measure axisX,Y,Z(optional)X,Y,Z(optional)X,Y,Z(optional)
    Bandwidth>2000Hz>2000Hz>2000Hz
    Resolution0.1°/s0.1°/s0.1°/s
    Nonlinear0.1% of FS0.1% of FS0.1% of FS
    Temperature drift< ±0.1°/sec,/℃< ±0.1°/sec,/℃< ±0.1°/sec,/℃
    Start time5ms5ms5ms
    Input voltage9~36V9~36V9~36V
    Output current4~20mA4~20mA4~20mA
    Current6mA6mA6mA
    Working temperature-40℃ ~+85℃-40℃ ~+85℃-40℃ ~+85℃
    Store temperature-40℃ ~+85℃-40℃ ~+85℃-40℃ ~+85℃
    Capacitive load1000Pf1000Pf1000Pf
    Shock5g~10g5g~10g5g~10g
    Impact200g pk,2ms,½sine
    Time Drift20°/h
    Working life11 years
    Electromagnetic compatibilityAccording to EN61000 and GBT17626
    MTBF≥98000hours/times
    Insulation resistance≥100M
    Shockproof100g@11ms,3 Axial Direction (Half Sinusoid)
    Anti-vibration10grms,10~1000Hz
    Protection classIP67
    Connector5 pins air-plug, matched with 1M cable
    Weight110g(Without cable)
